D2D0606N
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rotary Switches
Description
SWITCH ROTARY 2-6POS 250MA 115V
PDF
/
Buying Options
Total Price: USD $84.18
Unit Price: USD $84.1808
≥1 USD $84.1808
≥10 USD $79.0768
≥100 USD $76.01528
≥500 USD $69.638272
≥1000 USD $66.322256
Inventory: 91
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Contact Material Brass
Contact Plating Silver
Mount Panel
Mounting Type Panel Mount
Number of Pins 6
Technical
Published 2006
Series D2
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder
Number of Positions 2 ~ 6
Voltage - Rated DC 28V
Current Rating (Amps) 250mA AC 550mA DC
Orientation Vertical
Current Rating 550mA
Contact Finish Silver
Termination Style Solder Lug
Voltage - Rated AC 115V
Actuator Type Round (6.35mm Dia)
Panel Cutout Dimensions Circular - 9.78mm Dia
Contact Style Non-Shorting
Number of Poles 6
Throw Configuration DPDT
Number of Decks 3
Contact Timing Non-Shorting (BBM)
Index Stops Adjustable
Circuit per Deck DP6T
Depth Behind Panel 24.69mm
Index Angle 30 °
Number of Poles per Deck 2
Angle of Throw 30°
Dimensions
Actuator Length 25.40mm
Compliance
REACH SVHC Unknown
RoHS Status RoHS Compliant
Lead Free Lead Free
