C4D1006N-A
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rotary Switches
Description
SWITCH ROTARY 2-6POS 300MA 125V
PDF
/
Buying Options
Total Price: USD $78.46
Unit Price: USD $78.4608
≥1 USD $78.4608
≥10 USD $73.70352
≥100 USD $70.85056
≥500 USD $64.906688
≥1000 USD $61.816128
Inventory: 96
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Contact Material Brass
Mount Panel
Mounting Type Panel Mount
Technical
Published 2006
Series C4
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder
ECCN Code EAR99
Number of Positions 2 ~ 6
Voltage - Rated DC 28V
Current Rating (Amps) 300mA AC 500mA DC
Orientation Straight
Depth 48.9712mm
Reach Compliance Code unknown
Current Rating 500mA
Contact Finish Silver
Termination Style Solder Lug
Voltage - Rated AC 125V
Actuator Type Flatted (6.35mm Dia)
Panel Cutout Dimensions Circular - 9.78mm Dia
Contact Style Non-Shorting
Contact Resistance 3mOhm
Max Voltage Rating (AC) 125V
Max Voltage Rating (DC) 28V
Mechanical Life 25000 cycles
Switch Type ROTARY SWITCH
Number of Decks 5
Contact Timing Non-Shorting (BBM)
Index Stops Adjustable
Circuit per Deck DP6T
Depth Behind Panel 48.97mm
Index Angle 30 °
Number of Poles per Deck 2
Dimensions
Actuator Length 12.70mm
Compliance
RoHS Status RoHS Compliant
Lead Free Contains Lead
Ratings IP67
