C1D0306S-VA
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rotary Switches
Description
Rotary Switches SWITCH ROTARY 6 POS MINI
PDF
/
Buying Options
Total Price: USD $29.49
Unit Price: USD $29.493543
≥1 USD $29.493543
≥10 USD $27.824096
≥100 USD $26.249151
≥500 USD $24.763353
≥1000 USD $23.361643
Inventory: 987
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Actuator Length 9.52mm
Technical
Angle of Throw 30°
Number of Poles per Deck 1
Index Angle 30 °
Depth Behind Panel 30.76mm
Circuit per Deck SP6T
Index Stops Adjustable
Contact Timing Shorting (MBB)
Number of Decks 3
Throw Configuration SP6T
Number of Poles 3
Contact Style Shorting
Panel Cutout Dimensions Circular - 6.76mm Dia
Actuator Type Flatted (3.17mm Dia)
Voltage - Rated AC 125V
Termination Style PC Pin
Contact Finish Silver
Current Rating 250mA
Depth 30.7594mm
Current Rating (Amps) 100mA AC 250mA DC
Voltage - Rated DC 28V
Number of Positions 2 ~ 6
Termination PC Pin
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series C1
Published 2006
Physical
Number of Pins 6
Mounting Type Panel Mount, Through Hole, Right Angle
Mount Panel, Through Hole
Contact Plating Silver
Contact Material Brass
Supply Chain
Factory Lead Time 5 Weeks
