C1D0304N-A

Electroswitch
RoHS
RoHS RoHS compliant
Package /
Category Switches / Rotary Switches
Description Rotary Switches 02-04POS/3P/1 DECK
PDF
/
Buying Options
Total Price: USD $99.13
Unit Price: USD $99.130515
≥1 USD $99.130515
≥200 USD $39.553738
≥500 USD $38.232961
≥1000 USD $37.579137
Inventory: 1193
Minimum: 1
-
+

Technical Details

Technical

Contact Finish Silver
Termination Style Solder Lug
Voltage - Rated AC 125V
Actuator Type Flatted (3.17mm Dia)
Panel Cutout Dimensions Circular - 6.76mm Dia
Contact Style Non-Shorting
Insulation Resistance 10GOhm
Number of Poles 3
Throw Configuration 3P4T
Mechanical Life 25000 cycles
Number of Decks 1
Contact Timing Non-Shorting (BBM)
Index Stops Adjustable
Circuit per Deck 3P4T
Depth Behind Panel 20.60mm
Index Angle 30 °
Number of Poles per Deck 3
Current Rating 250mA
Current Rating (Amps) 100mA AC 250mA DC
Voltage - Rated DC 28V
Voltage - Rated 125V
Number of Positions 2 ~ 4
Termination Solder
Part Status Active
Series C1
Published 1997
Angle of Throw 30°

Physical

Mounting Type Panel Mount
Mount Panel
Contact Plating Silver
Contact Material Brass

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant

Dimensions

Actuator Length 9.52mm
Width 20mm
Length 20.6mm
Height 22mm
