KC43A10.001SPS
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rotary Switches
Description
SWITCH ROTARY 3POS 350MA 125V
PDF
/
Inventory: 8134
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 10.00mm
Technical
Angle of Throw 30°
Number of Poles per Deck 4
Index Angle 30 °
Depth Behind Panel 14.20mm
Circuit per Deck 4P3T
Index Stops Fixed
Contact Timing Shorting (MBB)
Operating Force 8.770gfm
Number of Decks 1
Contact Style Shorting
Panel Cutout Dimensions Circular - 9.80mm Dia
Actuator Type Flatted (6.35mm Dia)
Voltage - Rated AC 125V
Termination Style PC Pin
Contact Finish Silver
Current Rating 350mA
Current Rating (Amps) 350mA AC
Number of Positions 3
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series KC
Physical
Mounting Type Panel Mount, Through Hole
Mount Panel, Through Hole
Contact Plating Silver
Contact Material Copper Alloy
