KC23A30.001SLS
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rotary Switches
Description
SWITCH ROTARY 3POS 350MA 125V
PDF
/
Buying Options
Total Price: USD $12.39
Unit Price: USD $12.388524
≥1 USD $12.388524
≥200 USD $4.943069
≥500 USD $4.777643
≥1000 USD $4.696243
Inventory: 1100
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Contact Material Copper Alloy
Mount Panel
Mounting Type Panel Mount
Technical
Series KC
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Lug
Number of Positions 3
Current Rating (Amps) 350mA AC
Current Rating 350mA
Contact Finish Silver
Termination Style Solder Lug
Voltage - Rated AC 125V
Actuator Type Flatted (6.35mm Dia)
Panel Cutout Dimensions Circular - 9.80mm Dia
Contact Style Shorting
Switch Type ROTARY SWITCH
Number of Decks 1
Operating Force 8.770gfm
Contact Timing Shorting (MBB)
Index Stops Fixed
Circuit per Deck DP3T
Depth Behind Panel 18.50mm
Index Angle 30 °
Number of Poles per Deck 2
Dimensions
Actuator Length 30.00mm
Compliance
RoHS Status ROHS3 Compliant
