KC16A13.001NPS
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rotary Switches
Description
SWITCH ROTARY 6POS 350MA 125V
PDF
/
Buying Options
Total Price: USD $11.97
Unit Price: USD $11.971022
≥1 USD $11.971022
≥200 USD $4.777643
≥500 USD $4.617469
≥1000 USD $4.538695
Inventory: 6712
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 13.00mm
Technical
Bushing Type 3/8-32
Bushing Diameter 0.375 inch
PCB Hole Count 8
Index Angle 30 °
Depth Behind Panel 14.20mm
Circuit per Deck SP6T
Index Stops Fixed
Contact Voltage(AC)-Max 250V
Contact Timing Non-Shorting (BBM)
Operating Force 8.770gfm
Number of Decks 1
Switch Type ROTARY SWITCH
Contact Voltage(DC)-Max 250V
Contact Resistance 0.025mOhm
Contact Style Non-Shorting
Panel Cutout Dimensions Circular - 9.80mm Dia
Actuator Type Flatted (6.35mm Dia)
Operating Temperature (Max) 85°C
Body Length or Diameter 27.5082mm
Voltage - Rated AC 125V
Termination Style PC Pin
Contact Finish Silver
Current Rating 350mA
Current Rating (Amps) 350mA AC
Number of Positions 6
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series KC
Physical
Housing Material GLASS FILLED NYLON
Insulation Material GLASS FILLED NYLON
Mounting Type Panel Mount, Through Hole
Mount Panel, Through Hole
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 10 Weeks
