RTAP30BCSSD50S

C&K
RoHS
/
Package /
Category Switches / Rotary Switches
Description SWITCH ROTARY BINARY 50MM PCB
PDF
/
Inventory: 9403
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status Non-RoHS Compliant

Dimensions

Actuator Length 50.00mm

Technical

Angle of Throw 30°
Index Angle 30 °
Depth Behind Panel 12.60mm
Circuit per Deck BCD with Complement
Index Stops Continuous
Contact Timing Non-Shorting (BBM)
Operating Force 5.099gfm
Number of Decks 1
Max Voltage Rating (DC) 60V
Throw Configuration SP
Electrical Life 10000 cycles
Max Voltage Rating (AC) 60V
Actuator Type Round (5.9mm Dia)
Voltage - Rated AC 60V
Termination Style PC Pin
Contact Finish Silver
Current Rating 5A
Orientation Vertical
Current Rating (Amps) 150mA AC/DC
Voltage - Rated DC 60V
Number of Positions 10
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series RTA
Published 2003

Physical

Actuator Material Polysulfon, Thermoplastic
Housing Material Thermoplastic
Mounting Type Through Hole
Mount PCB, Through Hole
Contact Plating Silver
Contact Material Brass
