MD06S1NCQD
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rotary Switches
Description
SWITCH ROTARY 6POS 250MA 125V
PDF
/
Inventory: 4992
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Contact Material Copper Alloy
Mount Panel, Through Hole
Mounting Type Panel Mount, Through Hole
Housing Material Zinc
Actuator Material Stainless Steel
Technical
Published 2013
Series M
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pins
Number of Positions 6
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Voltage - Rated DC 28V
Current Rating (Amps) 250mA AC/DC
Orientation Straight
Depth 13.34mm
Current Rating 250mA
Contact Finish Silver
Termination Style PC Pin
Voltage - Rated AC 125V
Actuator Type Flatted (3.17mm Dia)
Panel Cutout Dimensions Circular - 6.60mm Dia
Contact Style Non-Shorting
Max Voltage Rating (AC) 125V
Max Current Rating 250mA
Electrical Life 10000 cycles
Max Voltage Rating (DC) 28V
Number of Decks 1
Operating Force 2.880 ~ 5.041gfm
Contact Timing Non-Shorting (BBM)
Index Stops Fixed
Circuit per Deck DP6T
Depth Behind Panel 10.42mm
Index Angle 30 °
Number of Poles per Deck 2
Dimensions
Length 13.34mm
Actuator Length 10.16mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
