MC07L2NCQF
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rotary Switches
Description
SWITCH ROTARY 7POS 250MA 125V
PDF
/
Inventory: 4741
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Actuator Length Flush
Length 13.34mm
Technical
Angle of Throw 30°
Number of Poles per Deck 1
Index Angle 30 °
Depth Behind Panel 10.42mm
Circuit per Deck SP7T
Index Stops Fixed
Contact Timing Non-Shorting (BBM)
Operating Force 2.880 ~ 5.041gfm
Number of Decks 1
Max Voltage Rating (DC) 28V
Throw Configuration SP7T
Max Current Rating 250mA
Max Voltage Rating (AC) 125V
Contact Style Non-Shorting
Panel Cutout Dimensions Circular - 6.60mm Dia
Actuator Type Screwdriver Slot
Voltage - Rated AC 125V
Termination Style PC Pin
Contact Finish Silver
Current Rating 250mA
Depth 13.34mm
Current Rating (Amps) 250mA AC/DC
Voltage - Rated DC 28V
Min Operating Temperature -30°C
Max Operating Temperature 85°C
Number of Positions 7
Termination PC Pins
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature IP67 - Dust Tight, Waterproof
Series M
Physical
Mounting Type Panel Mount, Through Hole
Mount Panel, Through Hole
Contact Plating Silver
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 20 Weeks
