MB00L1NCGD
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rotary Switches
Description
Flatted (3.17mm Dia) M DP5T 1 Rotary Switch 10.16mm 250mA 125V 2.880-5.041gfm
PDF
/
Buying Options
Total Price: USD $14.58
Unit Price: USD $14.578442
≥1 USD $14.578442
≥200 USD $5.641531
≥500 USD $5.443283
≥1000 USD $5.346129
Inventory: 3774
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 10.16mm
Length 13.34mm
Technical
Number of Poles per Deck 2
Index Angle 36 °
Depth Behind Panel 10.42mm
Circuit per Deck DP5T
Index Stops Continuous
Contact Timing Non-Shorting (BBM)
Operating Force 2.880 ~ 5.041gfm
Number of Decks 1
Max Voltage Rating (DC) 28V
Electrical Life 10000 cycles
Max Current Rating 250mA
Max Voltage Rating (AC) 125V
Contact Style Non-Shorting
Panel Cutout Dimensions Circular - 6.60mm Dia
Actuator Type Flatted (3.17mm Dia)
Voltage - Rated AC 125V
Termination Style PC Pin
Contact Finish Gold
Current Rating 250mA
Depth 13.34mm
Orientation Straight
Current Rating (Amps) 250mA AC/DC
Voltage - Rated DC 28V
Min Operating Temperature -30°C
Max Operating Temperature 85°C
Number of Positions 5
Termination PC Pins
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series M
Published 2014
Physical
Actuator Material Stainless Steel
Housing Material Zinc
Mounting Type Panel Mount, Through Hole
Mount Panel, Through Hole
Contact Plating Gold, Silver
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 20 Weeks
