MA06L3NZGF
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rotary Switches
Description
SWITCH ROTARY 6POS 250MA 125V
PDF
/
Inventory: 4515
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Contact Material Copper Alloy
Contact Plating Gold, Silver
Mount Panel
Mounting Type Panel Mount
Technical
Series M
Feature IP67 - Dust Tight, Waterproof
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Number of Positions 6
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Voltage - Rated DC 28V
Current Rating (Amps) 250mA AC/DC
Depth 13.34mm
Current Rating 250mA
Contact Finish Gold
Termination Style Solder Lug
Voltage - Rated AC 125V
Actuator Type Round (3.17mm Dia)
Panel Cutout Dimensions Circular - 6.60mm Dia
Contact Style Non-Shorting
Max Voltage Rating (AC) 125V
Max Current Rating 250mA
Throw Configuration SP6T
Max Voltage Rating (DC) 28V
Number of Decks 1
Operating Force 2.880 ~ 5.041gfm
Contact Timing Non-Shorting (BBM)
Index Stops Fixed
Circuit per Deck SP6T
Depth Behind Panel 14.86mm
Index Angle 36 °
Number of Poles per Deck 1
Angle of Throw 36°
Dimensions
Length 13.34mm
Actuator Length 10.16mm
Compliance
RoHS Status ROHS3 Compliant
