A30305RNCQE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rotary Switches
Description
Switch Rotary N.O./N.C. 3P3T 3 Flatted Shaft PC Pins 2.5A 125VAC 125VDC
PDF
/
Buying Options
Total Price: USD $17.01
Unit Price: USD $17.007307
≥1 USD $17.007307
Inventory: 5239
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 12.70mm
Length 26.19mm
Technical
Angle of Throw 30°
Number of Poles per Deck 3
Index Angle 30 °
Depth Behind Panel 14.48mm
Circuit per Deck 3P3T
Index Stops Fixed
Contact Timing Non-Shorting (BBM)
Number of Decks 1
Max Voltage Rating (DC) 125V
Throw Configuration 3P3T
Electrical Life 15000 cycles
Max Current Rating 2.5A
Max Voltage Rating (AC) 125V
Contact Style Non-Shorting
Panel Cutout Dimensions Circular - 9.80mm Dia
Actuator Type Flatted (6.35mm Dia)
Voltage - Rated AC 125V
Termination Style PC Pin
Contact Finish Silver
Current Rating 2.5A
Depth 26.19mm
Orientation Straight
Current Rating (Amps) 2.5A AC 350mA DC
Voltage - Rated DC 125V
Min Operating Temperature -30°C
Max Operating Temperature 85°C
Number of Positions 3
Termination PC Pins
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Epoxy Sealed Terminals
Series A
Published 2010
Physical
Actuator Material Glass, Nylon
Housing Material Nylon
Mounting Type Panel Mount, Through Hole
Mount Panel, Through Hole
Contact Plating Silver
Contact Material Silver (Ag)
Supply Chain
Factory Lead Time 16 Weeks
