A11205RSCB
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rotary Switches
Description
Switch Rotary N.O./N.C. SP12T 12 Flatted Shaft PC Pins 20VAC 20VDC 0.4VA
PDF
/
Buying Options
Total Price: USD $19.47
Unit Price: USD $19.467681
≥1 USD $19.467681
Inventory: 6765
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Contact Plating Gold
Mount Panel, Through Hole
Mounting Type Panel Mount, Through Hole
Housing Material Nylon
Actuator Material Glass, Nylon
Technical
Published 2010
Series A
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pins
Number of Positions 12
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Voltage - Rated DC 20V
Current Rating (Amps) 0.4VA AC/DC
Orientation Straight
Depth 26.19mm
Contact Finish Gold
Termination Style PC Pin
Voltage - Rated AC 20V
Actuator Type Flatted (6.35mm Dia)
Panel Cutout Dimensions Circular - 9.80mm Dia
Contact Style Shorting
Max Voltage Rating (AC) 20V
Electrical Life 300000 cycles
Throw Configuration SP12T
Max Voltage Rating (DC) 20V
Number of Decks 1
Contact Timing Shorting (MBB)
Index Stops Fixed
Circuit per Deck SP12T
Depth Behind Panel 14.48mm
Index Angle 30 °
Number of Poles per Deck 1
Angle of Throw 30°
Dimensions
Length 26.19mm
Actuator Length 12.70mm
Compliance
RoHS Status ROHS3 Compliant
