A11205RNCBE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rotary Switches
Description
Switch Rotary N.O./N.C. SP12T 12 Flatted Shaft PC Pins 20VAC 20VDC 0.4VA Automotive
PDF
/
Buying Options
Total Price: USD $23.02
Unit Price: USD $23.017763
≥1 USD $23.017763
Inventory: 4882
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 12.70mm
Length 26.19mm
Technical
Angle of Throw 30°
Number of Poles per Deck 1
Index Angle 30 °
Depth Behind Panel 14.48mm
Circuit per Deck SP12T
Index Stops Fixed
Contact Timing Non-Shorting (BBM)
Number of Decks 1
Max Voltage Rating (DC) 20V
Throw Configuration SP12T
Electrical Life 300000 cycles
Max Voltage Rating (AC) 20V
Contact Style Non-Shorting
Panel Cutout Dimensions Circular - 9.80mm Dia
Actuator Type Flatted (6.35mm Dia)
Voltage - Rated AC 20V
Termination Style PC Pin
Contact Finish Gold
Depth 26.19mm
Orientation Straight
Current Rating (Amps) 0.4VA AC/DC
Voltage - Rated DC 20V
Min Operating Temperature -30°C
Max Operating Temperature 85°C
Number of Positions 12
Termination PC Pins
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Epoxy Sealed Terminals
Series A
Published 2010
Physical
Actuator Material Glass, Nylon
Housing Material Nylon
Mounting Type Panel Mount, Through Hole
Mount Panel, Through Hole
Contact Plating Gold
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 16 Weeks
