287T328S202A11
RoHS
RoHS compliant
RoHS compliantPackage /
Category Potentiometers, Variable Resistors / Rotary Potentiometers, Rheostats
Description
User Defined RoHS Compliant Cermet Linear rotary potentiometer ±10% 312° 2W 0.875 22.23mm
PDF
/
Buying Options
Total Price: USD $19.26
Unit Price: USD $19.2632
≥1 USD $19.2632
≥10 USD $17.7232
≥100 USD $14.641088
≥500 USD $13.10012
≥1000 USD $12.32946
≥3000 USD $11.558835
Inventory: 166
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mounting Type Panel Mount
Resistive Material Cermet
Technical
Series 287
Tolerance ±10%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Resistance 2kOhm
Power (Watts) 2W
Termination Style Solder Lug
Actuator Type Slotted
Bushing Thread 3/8-32
Adjustment Type User Defined
Number of Turns 1
Taper Linear
Built in Switch None
Actuator Diameter 0.375 (9.53mm)
Rotation 312°
Size - Body Round - 1.051Dia x 0.494 H 26.70mmx12.55mm
Dimensions
Actuator Length 0.875 22.23mm
Compliance
RoHS Status RoHS Compliant
