M2012TZW23
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
Actuator Arm Cap Required M Through Hole Bulk Rocker Switch 0.433inch 3A 250V 3A@250VAC
PDF
/
Inventory: 8750
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Insulation Material DIALLYL PHTHALATE
Housing Material STAINLESS STEEL
Actuator Material NYLON
Center Contact Plating SILVER
Center Contact Material SILVER
Terminal Material COPPER ALLOY
End Contact Material SILVER
End Contact Plating SILVER
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Published 2015
Series M
JESD-609 Code e4
Feature Epoxy Sealed Terminals
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
ECCN Code EAR99
Terminal Finish GOLD OVER NICKEL/SILVER
Voltage - Rated DC 30V
Current Rating (Amps) 6A AC 4A DC
Current Rating 4A
Termination Style PC Pin
Voltage - Rated AC 125V
Actuator Type Actuator Arm, Cap Required
Circuit SPDT
Switch Function On-On
Insulation Resistance 1000000000Ohm
Dielectric Withstanding Voltage 1500VAC V
Electrical Life 25,000 Cycles
Mechanical Life 50,000 Cycles
Switch Type ROCKER SWITCH
Contact Current(AC)-Max 3A
Contact (AC) Max Rating R Load 3A@250VAC
Contact Voltage(AC)-Max 250V
Actuator Marking Varies by Cap
PCB Hole Count 7
Actuator Color BLACK
Solderability WAVE
Actuator Angle 25 deg
Dimensions
Length - Termination 0.189 inch
Actuator Length 0.433 inch
Compliance
RoHS Status ROHS3 Compliant
