RBW2ABLKGILFF2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
Illuminated Rocker Switches Fully Illuminated IP66 Rocker Switch
PDF
/
Buying Options
Total Price: USD $5.37
Unit Price: USD $5.368
≥1 USD $5.368
≥10 USD $4.82064
≥100 USD $4.598528
≥500 USD $4.400704
≥1000 USD $4.352744
Inventory: 1169
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 0.346 inch
Length - Termination 0.394 inch
Body Height 19.304mm
Technical
Contact (AC) Max Power Rating R Load 0.3HP@125VAC
Contact Function OFF-ON
Actuator Marking O -
Contact (AC) Max Rating R Load 16A@125VAC
Illumination Type Illuminated
Switch Type ROCKER SWITCH
Mechanical Life 50,000 Cycles
Electrical Life 50,000 Cycles
Dielectric Withstanding Voltage 1000VAC V
Illumination Type, Color Neon, Green
Illumination Voltage (Nominal) 250VAC
Color - Actuator/Cap Green
Insulation Resistance 500000000Ohm
Contact Resistance 0.03mOhm
Panel Cutout Dimensions Rectangular - 30.00mm x 22.30mm
Switch Function On-Off
Circuit DPST
Actuator Type Concave (Curved) - Illuminated
Body Breadth 22.098 mm
Body Length or Diameter 27.9908mm
Voltage - Rated AC 125V
Termination Style Quick Connect - 0.250 (6.3mm)
Current Rating 16A
Ingress Protection IP66 - Dust Tight, Water Resistant
Current Rating (Amps) 16A AC
Color Black
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series RBW2
Published 2011
Packaging Bulk
Operating Temperature -20°C~85°C
Physical
Surface Mount NO
Mounting Type Panel Mount, Snap-In
Contact Material Silver
Supply Chain
Factory Lead Time 9 Weeks
