RB143C112R
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
SWITCH ROCKER SPDT 15A 125V
PDF
/
Inventory: 10017
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Panel Mount, Snap-In
Surface Mount NO
Insulation Material POLYAMIDE
Center Contact Plating SILVER
Center Contact Material COPPER
End Contact Material COPPER
End Contact Plating SILVER
Technical
Operating Temperature -20°C~65°C
Packaging Bulk
Published 2011
Series RB1, LAMB
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Current Rating (Amps) 15A AC
Termination Style Quick Connect - 0.250 (6.3mm)
Voltage - Rated AC 125V
Body Length or Diameter 27.0002mm
Body Breadth 10.8966 mm
Actuator Type Concave (Curved)
Circuit SPDT
Switch Function On-On
Panel Cutout Dimensions Rectangular - 30.00mm x 11.00mm
Contact Resistance 0.035mOhm
Insulation Resistance 100000000Ohm
Color - Actuator/Cap Black
Dielectric Withstanding Voltage 1500VAC V
Electrical Life 10,000 Cycles
Switch Type ROCKER SWITCH
Contact Current(AC)-Max 15A
Contact Voltage(AC)-Max 125V
Actuator Marking O I
Dimensions
Actuator Length 0.339 inch
Compliance
RoHS Status ROHS3 Compliant
