RB141C1000-124
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
SWITCH ROCKER SPST 15A 125V
PDF
/
Buying Options
Total Price: USD $2.28
Unit Price: USD $2.277882
≥1 USD $2.277882
≥250 USD $0.90984
≥500 USD $0.879643
≥1000 USD $0.863888
Inventory: 3734
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Panel, Snap in
Mounting Type Panel Mount, Snap-In
Insulation Material POLYAMIDE
Actuator Material POLYCARBONATE
Center Contact Plating SILVER
Center Contact Material COPPER
End Contact Material COPPER
End Contact Plating SILVER
Technical
Operating Temperature -20°C~65°C
Packaging Bulk
Published 2011
Series RB1, LAMB
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Quick Connect
ECCN Code EAR99
Current Rating (Amps) 15A AC
Current Rating 15A
Termination Style Quick Connect - 0.250 (6.3mm)
Voltage - Rated AC 125V
Body Length or Diameter 27.2034mm
Body Breadth 10.8966 mm
Actuator Type Concave (Curved) - Illuminated
Circuit SPST
Switch Function On-Off
Panel Cutout Dimensions Rectangular - 30.00mm x 11.00mm
Contact Resistance 0.035mOhm
Insulation Resistance 100000000Ohm
Color - Actuator/Cap Amber
Illumination Voltage (Nominal) 12VDC
Illumination Type, Color Incandescent, Amber
Dielectric Withstanding Voltage 1500VAC V
Electrical Life 10,000 Cycles
Switch Type ROCKER SWITCH
Contact (AC) Max Rating R Load 15A@125VAC
Actuator Marking No Marking
Contact Function OFF-ON
Body Color BLACK
Dimensions
Body Height 16.6878mm
Length - Termination 0.394 inch
Actuator Length 0.343 inch
Compliance
RoHS Status ROHS3 Compliant
