RA45HC1911
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
SWITCH ROCKER DPDT 16A 125V
PDF
/
Inventory: 4665
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Panel, Snap in
Mounting Type Panel Mount, Snap-In
Insulation Material POLYAMIDE
Actuator Material POLYAMIDE
Center Contact Material SILVER ALLOY
Terminal Material COPPER
End Contact Material SILVER ALLOY
Technical
Operating Temperature -20°C~105°C
Packaging Bulk
Published 2011
Series RA4, LAMB
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Current Rating (Amps) 16A AC
Current Rating 16A
Termination Style Solder Lug
Voltage - Rated AC 125V
Body Length or Diameter 21.59mm
Body Breadth 18.5928 mm
Actuator Type Concave (Curved)
Circuit DPDT
Switch Function On-Mom
Panel Cutout Dimensions Rectangular - 22.00mm x 19.20mm
Contact Resistance 0.035mOhm
Insulation Resistance 100000000Ohm
Color - Actuator/Cap Red
Dielectric Withstanding Voltage 1500VAC V
Electrical Life 10,000 Cycles
Switch Type ROCKER SWITCH
Contact (AC) Max Rating R Load 16A@125VAC
Actuator Marking O -
Contact Function ON-(ON)
Body Color BLACK
Contact (AC) Max Power Rating R Load 0.3HP@250VAC
Dimensions
Body Height 12.192mm
Actuator Length 0.233 inch
Compliance
RoHS Status ROHS3 Compliant
