R5ABLKREDEF0
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
Rocker Switches 15A 250V DPST On-OffNo Lamp
PDF
/
Buying Options
Total Price: USD $3.75
Unit Price: USD $3.749642
≥1 USD $3.749642
≥225 USD $1.496706
≥525 USD $1.446816
≥975 USD $1.421871
Inventory: 1499
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Actuator Marking No Marking
Switch Type ROCKER SWITCH
Mechanical Life 30,000 Cycles
Electrical Life 10,000 Cycles
Color - Actuator/Cap Red
Panel Cutout Dimensions Rectangular - 30.00mm x 22.20mm
Switch Function On-Off
Circuit DPST
Actuator Type Concave (Curved)
Voltage - Rated AC 125V
Termination Style Quick Connect - 0.250 (6.3mm)
Current Rating 20A
Current Rating (Amps) 20A AC
ECCN Code EAR99
Termination Quick Connect
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series R5
Published 2008
Packaging Bulk
Operating Temperature -20°C~55°C
Physical
Mounting Type Panel Mount, Snap-In
Mount Panel, Snap in
Supply Chain
Factory Lead Time 10 Weeks
