R1973BBLKREDFF1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
Rocker Switches DPST 125VAC ILUM ROCKER SWITCH
PDF
/
Inventory: 8427
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 0.244 inch
Length - Termination 0.327 inch
Body Height 13.9954mm
Technical
Actuator Marking O -
Contact Voltage(AC)-Max 250V
Contact (AC) Max Rating R Load 6A@250VAC
Contact Current(AC)-Max 6A
Illumination Type Illuminated, Neon
Switch Type ROCKER SWITCH
Mechanical Life 30,000 Cycles
Electrical Life 10,000 Cycles
Dielectric Withstanding Voltage 3000VRMS V
Illumination Type, Color Neon, Red
Illumination Voltage (Nominal) 125VAC
Color - Actuator/Cap Red
Insulation Resistance 1000000000Ohm
Contact Resistance 0.02mOhm
Panel Cutout Dimensions Rectangular - 19.20mm x 12.80mm
Switch Function On-Off
Circuit DPST
Actuator Type Concave (Curved) - Illuminated
Body Breadth 12.5984 mm
Body Length or Diameter 18.5928mm
Voltage - Rated AC 125V
Termination Style Quick Connect - 0.187 (4.7mm)
Current Rating 9A
Current Rating (Amps) 9A AC
Color Black
ECCN Code EAR99
Termination Quick Connect
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series R1973
Published 2008
Packaging Bulk
Operating Temperature -30°C~55°C
Physical
Terminal Material COPPER ALLOY
Actuator Material POLYCARBONATE
Insulation Material NYLON
Mounting Type Panel Mount, Snap-In
Mount Panel, Snap in
Contact Plating Silver
Supply Chain
Factory Lead Time 10 Weeks
