R1973ABLKYELFF4
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
Concave (Curved) - Illuminated R1973 Yellow Panel Mount Snap-In Rocker Switch 0.244inch 6A 250V 6A@250VAC
PDF
/
Inventory: 3821
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 0.244 inch
Length - Termination 0.327 inch
Body Height 13.9954mm
Technical
Actuator Marking O -
Contact Voltage(AC)-Max 250V
Contact (AC) Max Rating R Load 6A@250VAC
Contact Current(AC)-Max 6A
Switch Type ROCKER SWITCH
Mechanical Life 30,000 Cycles
Electrical Life 10,000 Cycles
Dielectric Withstanding Voltage 3000VRMS V
Illumination Type, Color Incandescent, Yellow
Illumination Voltage (Nominal) 24VDC
Color - Actuator/Cap Yellow
Insulation Resistance 1000000000Ohm
Contact Resistance 0.02mOhm
Panel Cutout Dimensions Rectangular - 19.20mm x 12.80mm
Switch Function On-Off
Circuit SPST
Actuator Type Concave (Curved) - Illuminated
Body Breadth 12.5984 mm
Body Length or Diameter 18.5928mm
Voltage - Rated AC 125V
Termination Style Quick Connect - 0.187 (4.7mm)
Current Rating 9A
Current Rating (Amps) 9A AC
ECCN Code EAR99
Termination Quick Connect
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series R1973
Packaging Bulk
Operating Temperature -30°C~55°C
Physical
End Contact Plating SILVER
End Contact Material COIN SILVER
Terminal Material COPPER ALLOY
Center Contact Material COIN SILVER
Center Contact Plating SILVER
Actuator Material POLYCARBONATE
Insulation Material NYLON
Mounting Type Panel Mount, Snap-In
Mount Panel, Snap in
