R1966HBLKREDCF
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
SWITCH ROCKER SPDT 15A 125V
PDF
/
Inventory: 9858
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 0.167 inch
Length - Termination 0.26 inch
Body Height 13.9954mm
Technical
Contact Function ON-OFF-(ON)
Actuator Marking - O =
Contact Voltage(AC)-Max 250V
Contact (AC) Max Rating R Load 8A@250VAC
Contact Current(AC)-Max 8A
Switch Type ROCKER SWITCH
Mechanical Life 30,000 Cycles
Electrical Life 10,000 Cycles
Dielectric Withstanding Voltage 1500VAC V
Color - Actuator/Cap Red
Insulation Resistance 1000000000Ohm
Contact Resistance 0.02mOhm
Panel Cutout Dimensions Rectangular - 19.40mm x 13.00mm
Switch Function On-Off-Mom
Circuit SPDT
Actuator Type Concave (Curved)
Body Breadth 12.9032 mm
Body Length or Diameter 18.4912mm
Voltage - Rated AC 125V
Termination Style Quick Connect - 0.187 (4.7mm)
Current Rating (Amps) 15A AC
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series R1966
Published 2008
Packaging Bulk
Operating Temperature -30°C~65°C
Physical
End Contact Plating SILVER
End Contact Material SILVER ALLOY
Terminal Material COPPER ALLOY
Center Contact Material SILVER ALLOY
Center Contact Plating SILVER
Actuator Material POLYCARBONATE
Insulation Material NYLON
Surface Mount NO
Mounting Type Panel Mount, Snap-In
