R1966FBLKBLKAG
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
Illuminated Rocker Switches ROCKER
PDF
/
Buying Options
Total Price: USD $1.8
Unit Price: USD $1.804
≥1 USD $1.804
≥10 USD $1.6148
≥100 USD $1.526976
≥500 USD $1.453936
≥1000 USD $1.388112
≥3000 USD $1.32968
Inventory: 49
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Contact Plating Silver
Mount Panel, Snap in
Mounting Type Panel Mount, Snap-In
Housing Material Nylon
Actuator Material POLYCARBONATE
Terminal Material COPPER ALLOY
Technical
Operating Temperature -30°C~65°C
Packaging Bulk
Series R1966
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Quick Connect
ECCN Code EAR99
Current Rating (Amps) 15A AC
Current Rating 15A
Termination Style Quick Connect - 0.187 (4.7mm)
Voltage - Rated AC 125V
Body Length or Diameter 18.5928mm
Body Breadth 13.0048 mm
Actuator Type Concave (Curved)
Circuit SPST-NO
Switch Function Off-Mom
Panel Cutout Dimensions Rectangular - 19.40mm x 13.00mm
Contact Resistance 0.02mOhm
Insulation Resistance 1000000000Ohm
Color - Actuator/Cap Black
Dielectric Withstanding Voltage 1500VAC V
Electrical Life 10,000 Cycles
Throw Configuration SPST
Mechanical Life 30,000 Cycles
Switch Type ROCKER SWITCH
Illumination Type LED
Contact Current(AC)-Max 6A
Contact (AC) Max Rating R Load 6A@250VAC
Contact Voltage(AC)-Max 250V
Actuator Marking Dot
Contact Function OFF-(ON)
Dimensions
Body Height 13.8938mm
Length - Termination 0.287 inch
Actuator Length 0.217 inch
Compliance
RoHS Status ROHS3 Compliant
