R1966ABLKWHTEFGRN
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
Illuminated Rocker Switches SPST ON-OFF GREEN
PDF
/
Inventory: 6764
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 0.217 inch
Length - Termination 0.287 inch
Body Height 13.0048mm
Technical
Body Color BLACK
Actuator Marking No Marking
Contact Voltage(AC)-Max 250V
Contact (AC) Max Rating R Load 6A@250VAC
Contact Current(AC)-Max 6A
Illumination Color Green
Illumination Type Illuminated, LED
Switch Type ROCKER SWITCH
Mechanical Life 30,000 Cycles
Electrical Life 10,000 Cycles
Sealing MOLDED
Illumination Type, Color LED, Green
Illumination Voltage (Nominal) 2.2VDC
Color - Actuator/Cap White
Insulation Resistance 1000000000Ohm
Contact Resistance 0.01mOhm
Panel Cutout Dimensions Rectangular - 19.40mm x 13.00mm
Switch Function On-Off
Circuit SPST
Actuator Type Concave (Curved) - Illuminated
Body Breadth 13.0048 mm
Body Length or Diameter 18.5928mm
Voltage - Rated AC 125V
Termination Style Quick Connect - 0.187 (4.7mm)
Current Rating 15A
Current Rating (Amps) 15A AC
Additional Feature SNAP-IN TYPE PANEL MOUNTING
Termination Quick Connect
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series R1966
Published 2008
Packaging Bulk
Operating Temperature -30°C~65°C
Physical
Terminal Material COPPER ALLOY
Actuator Material POLYCARBONATE
Insulation Material NYLON
Mounting Type Panel Mount, Snap-In
Mount Panel, Snap in
Contact Plating Silver
