R1966ABLKBLKIS
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
SWITCH ROCKER SPST 15A 125V
PDF
/
Buying Options
Total Price: USD $1.28
Unit Price: USD $1.276
≥1 USD $1.276
≥10 USD $1.1396
≥100 USD $1.078176
≥500 USD $1.027312
≥1000 USD $0.981244
≥3000 USD $0.935246
Inventory: 1177
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Body Height 14mm
Technical
Actuator Marking ON OFF, Vertical
Contact (AC) Max Rating R Load 15A@125VAC
Illumination Type Illuminated
Contact Current Rating 15A
Switch Type ROCKER SWITCH
Mechanical Life 30,000 Cycles
Electrical Life 10,000 Cycles
Color - Actuator/Cap Black
Panel Cutout Dimensions Rectangular - 19.40mm x 13.00mm
Switch Function On-Off
Circuit SPST
Actuator Type Concave (Curved)
Body Breadth 12.9 mm
Body Length or Diameter 21mm
Voltage - Rated AC 125V
Termination Style Solder Lug
Current Rating 15A
Orientation Vertical
Current Rating (Amps) 15A AC
HTS Code 8536.50.90.65
ECCN Code EAR99
Termination Lug
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series R1966
Published 2001
Packaging Bulk
Operating Temperature -30°C~65°C
Physical
Mounting Type Panel Mount, Snap-In
Mount Panel, Snap in
Contact Material Silver
Supply Chain
Factory Lead Time 10 Weeks
