R1966ABLKBLKAS
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
SWITCH ROCKER SPST 15A 125V
PDF
/
Inventory: 7225
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Panel, Snap in
Mounting Type Panel Mount, Snap-In
Insulation Material NYLON
Actuator Material POLYCARBONATE
Center Contact Plating SILVER
Center Contact Material COIN SILVER
Terminal Material COPPER ALLOY
End Contact Material COIN SILVER
End Contact Plating SILVER
Technical
Operating Temperature -30°C~65°C
Packaging Bulk
Published 2012
Series R1966
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Current Rating (Amps) 15A AC
Current Rating 15A
Termination Style Solder Lug
Voltage - Rated AC 125V
Body Length or Diameter 18.5928mm
Actuator Type Concave (Curved)
Circuit SPST
Switch Function On-Off
Panel Cutout Dimensions Rectangular - 19.40mm x 13.00mm
Contact Resistance 0.02mOhm
Insulation Resistance 1000000000Ohm
Color - Actuator/Cap Black
Dielectric Withstanding Voltage 1500VAC V
Electrical Life 10,000 Cycles
Mechanical Life 30,000 Cycles
Switch Type ROCKER SWITCH
Contact Current(AC)-Max 8A
Contact (AC) Max Rating R Load 8A@250VAC
Contact Voltage(AC)-Max 250V
Actuator Marking Dot
Dimensions
Body Height 13.9954mm
Compliance
RoHS Status ROHS3 Compliant
