400MSP1R1BLKM7QE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
SWITCH ROCKER SPDT 3A 120V
PDF
/
Buying Options
Total Price: USD $3.39
Unit Price: USD $3.388
≥1 USD $3.388
≥10 USD $3.03688
≥100 USD $2.49979
≥500 USD $2.174946
Inventory: 396
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 5.08mm
Length 8.13mm
Height 8.43mm
Technical
Actuator Marking No Marking
Contact Current Rating 3A
Max Voltage Rating (DC) 28V
Throw Configuration SPDT
Electrical Life 30,000 Cycles
Max Voltage Rating (AC) 250V
Color - Actuator/Cap Black
Contact Resistance 20mOhm
Switch Function On-On
Circuit SPDT
Actuator Type Concave (Curved)
Voltage - Rated AC 120V
Termination Style PC Pin
Current Rating 3A
Orientation Vertical
Current Rating (Amps) 3A AC/DC
Voltage - Rated DC 28V
Min Operating Temperature -30°C
Max Operating Temperature 85°C
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Epoxy Sealed Terminals
Series 400
Published 2008
Packaging Bulk
Operating Temperature -30°C~85°C
Physical
Actuator Material Nylon
Housing Material Stainless Steel
Mounting Type Through Hole, Right Angle, Vertical
Mount Brackets, Through Hole, Vertical
Contact Plating Silver
Contact Material Silver
Supply Chain
Factory Lead Time 9 Weeks
