400MDP1R1REDM7QE

E-Switch
RoHS
RoHS RoHS compliant
Package /
Category Switches / Rocker Switches
Description SWITCH ROCKER DPDT 3A 120V
PDF
/
Inventory: 9744
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 9 Weeks

Physical

Contact Plating Silver
Mount Through Hole, Vertical
Mounting Type Through Hole, Right Angle, Vertical
Housing Material Stainless Steel
Actuator Material NYLON
Center Contact Material COPPER ALLOY
Terminal Material COPPER ALLOY

Technical

Operating Temperature -30°C~85°C
Packaging Bulk
Series 400
Feature Epoxy Sealed Terminals
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Voltage - Rated DC 28V
Current Rating (Amps) 3A AC/DC
Current Rating 3A
Termination Style PC Pin
Voltage - Rated AC 120V
Body Breadth 8.128 mm
Actuator Type Concave (Curved)
Circuit DPDT
Switch Function On-On
Contact Resistance 0.02mOhm
Insulation Resistance 1000000000Ohm
Color - Actuator/Cap Red
Contact Current(DC)-Max 3A
Dielectric Withstanding Voltage 1000VRMS V
Electrical Life 30,000 Cycles
Switch Type ROCKER SWITCH
Contact Current(AC)-Max 1A
Contact (AC) Max Rating R Load 1A@250VAC
Contact Voltage(AC)-Max 250V
Actuator Marking No Marking
PCB Hole Count 7

Dimensions

Body Height 14.1224mm
Actuator Length 0.417 inch

Compliance

RoHS Status ROHS3 Compliant
