300SP2J3BLKM6QE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
SWITCH ROCKER SPDT 5A 120V
PDF
/
Buying Options
Total Price: USD $8.16
Unit Price: USD $8.164925
≥1 USD $8.164925
≥200 USD $3.258618
≥500 USD $3.149647
≥1000 USD $3.095818
Inventory: 3218
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length - Termination 0.125 inch
Body Height 12.7mm
Technical
Actuator Angle 25 deg
Contact Function ON-(ON)
PCB Hole Count 5
Actuator Marking No Marking
Contact Voltage(AC)-Max 250V
Contact (AC) Max Rating R Load 2A@250VAC
Contact Current(AC)-Max 2A
Switch Type ROCKER SWITCH
Electrical Life 40,000 Cycles
Dielectric Withstanding Voltage 1000VRMS V
Contact Current(DC)-Max 5A
Color - Actuator/Cap Black
Insulation Resistance 1000000000Ohm
Contact Resistance 0.01mOhm
Switch Function On-Mom
Circuit SPDT
Actuator Type Concave (Standard V)
Body Length or Diameter 12.7mm
Voltage - Rated AC 120V
Termination Style PC Pin
Current Rating 5A
Current Rating (Amps) 5A AC/DC
Voltage - Rated DC 28V
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Epoxy Sealed Terminals
Series 300
Published 2015
Packaging Bulk
Operating Temperature -30°C~85°C
Physical
End Contact Material COPPER ALLOY
Terminal Material COPPER ALLOY
Center Contact Material COPPER ALLOY
Housing Material Stainless Steel
Mounting Type Through Hole, Right Angle
Mount Through Hole
Contact Plating Silver
Supply Chain
Factory Lead Time 9 Weeks
