300SP1J3BLKVS5QE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
Concave (Standard V) 300 Black Through Hole Rocker Switch 2A 250V 2A@250VAC 0.01mOhm
PDF
/
Inventory: 4026
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
PCB Hole Count 7
Actuator Marking No Marking
Contact Voltage(AC)-Max 250V
Contact (AC) Max Rating R Load 2A@250VAC
Contact Current(AC)-Max 2A
Switch Type ROCKER SWITCH
Electrical Life 40,000 Cycles
Dielectric Withstanding Voltage 1000VRMS V
Contact Current(DC)-Max 5A
Color - Actuator/Cap Black
Insulation Resistance 1000000000Ohm
Contact Resistance 0.01mOhm
Switch Function On-On
Circuit SPDT
Actuator Type Concave (Standard V)
Voltage - Rated AC 120V
Termination Style PC Pin
Current Rating 5A
Current Rating (Amps) 5A AC/DC
Voltage - Rated DC 28V
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Epoxy Sealed Terminals
Series 300
Packaging Bulk
Operating Temperature -30°C~85°C
Physical
End Contact Material COPPER ALLOY
Center Contact Material COPPER ALLOY
Housing Material Stainless Steel
Mounting Type Through Hole
Mount Through Hole
Contact Plating Silver
Supply Chain
Factory Lead Time 9 Weeks
