300DP5J1BLKM7RE

E-Switch
RoHS
RoHS RoHS compliant
Package /
Category Switches / Rocker Switches
Description SWITCH ROCKER DPDT 0.4VA 20V
PDF
/
Inventory: 5290
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 9 Weeks

Physical

Contact Plating Gold
Terminal Material COPPER ALLOY
Center Contact Material COPPER ALLOY
Housing Material Stainless Steel
Mounting Type Through Hole, Right Angle, Vertical
Mount Through Hole, Vertical

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Actuator Length 0.548 inch
Length - Termination 0.125 inch
Body Height 20.955mm

Technical

Contact (AC) Max Power Rating R Load 0.4VA@20VAC
Contact Function ON-OFF-(ON)
Actuator Marking No Marking
Switch Type ROCKER SWITCH
Electrical Life 40,000 Cycles
Dielectric Withstanding Voltage 1000VRMS V
Color - Actuator/Cap Black
Insulation Resistance 1000000000Ohm
Contact Resistance 0.01mOhm
Switch Function On-Off-Mom
Circuit DPDT
Actuator Type Concave (Standard V)
Body Breadth 11.43 mm
Voltage - Rated AC 20V
Termination Style PC Pin
Current Rating 400mA
Orientation Vertical
Current Rating (Amps) 0.4VA AC/DC
Voltage - Rated DC 20V
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Epoxy Sealed Terminals
Series 300
Published 2004
Packaging Bulk
Operating Temperature -30°C~85°C
