300AWSP1J1VS21RE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
Rocker Switches Mini Rocker Sealed SPDT 0.4VA 20V
PDF
/
Inventory: 6525
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Contact Plating Silver
Mount Through Hole
Mounting Type Through Hole
Housing Material GLASS FILLED NYLON
Actuator Material NYLON
Center Contact Material COPPER ALLOY
Terminal Material COPPER ALLOY
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Published 2003
Series 300A
Feature Epoxy Sealed Terminals
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
ECCN Code EAR99
Terminal Finish GOLD/NICKEL
Power Rating 400mW
Voltage - Rated DC 20V
Current Rating (Amps) 0.4VA AC/DC
Ingress Protection IP67 - Dust Tight, Waterproof
Current Rating 100mA
Termination Style PC Pin
Voltage - Rated AC 20V
Body Length or Diameter 15.7734mm
Body Breadth 8.128 mm
Actuator Type Concave (Standard V)
Circuit SPDT
Switch Function On-On
Contact Resistance 0.01mOhm
Insulation Resistance 1000000000Ohm
Color - Actuator/Cap Black
Dielectric Withstanding Voltage 1000VRMS V
Electrical Life 30,000 Cycles
Switch Type ROCKER SWITCH
Illumination Type Illuminated
Actuator Marking No Marking
PCB Hole Count 7
Dimensions
Body Height 11.684mm
Length - Termination 0.185 inch
Compliance
RoHS Status ROHS3 Compliant
Ratings Dust Tight, IP67, Waterproof
