300AWDP3J1VS2QE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
Rocker Switches Mini Rocker Sealed DPDT 5A 120V
PDF
/
Inventory: 2202
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Contact Plating Silver
Mount Through Hole
Mounting Type Through Hole
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Published 2017
Series 300A
Feature Epoxy Sealed Terminals
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Voltage - Rated DC 28V
Current Rating (Amps) 5A AC/DC
Ingress Protection IP67 - Dust Tight, Waterproof
Current Rating 5A
Termination Style PC Pin
Voltage - Rated AC 120V
Actuator Type Concave (Standard V)
Circuit DPDT
Switch Function On-Off-On
Color - Actuator/Cap Black
Electrical Life 30,000 Cycles
Illumination Type Illuminated
Actuator Marking No Marking
Compliance
RoHS Status ROHS3 Compliant
Ratings Dust Tight, IP67, Waterproof
