300AWDP2J6BLKVS3QE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
Rocker Switches Mini Rocker Sealed DPDT 5A 120V
PDF
/
Inventory: 5896
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Plating Silver
Mounting Type Through Hole
Surface Mount NO
Housing Material GLASS FILLED NYLON
Actuator Material NYLON
Center Contact Material COPPER ALLOY
Terminal Material COPPER ALLOY
End Contact Material COPPER ALLOY
Technical
Operating Temperature -30°C~85°C
Packaging Tray
Published 2009
Series 300A
Feature Epoxy Sealed Terminals
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Pin
Voltage - Rated DC 28V
Current Rating (Amps) 5A AC/DC
Ingress Protection IP67 - Dust Tight, Waterproof
Current Rating 100mA
Termination Style PC Pin
Voltage - Rated AC 120V
Body Breadth 11.43 mm
Actuator Type Paddle
Circuit DPDT
Switch Function On-Mom
Contact Resistance 0.01mOhm
Insulation Resistance 1000000000Ohm
Color - Actuator/Cap Black
Contact Current(DC)-Max 5A
Dielectric Withstanding Voltage 1000VRMS V
Electrical Life 30,000 Cycles
Switch Type TOGGLE SWITCH
Illumination Type Illuminated
Contact Current(AC)-Max 2A
Contact (AC) Max Rating R Load 2A@250VAC
Contact Voltage(AC)-Max 250V
Actuator Marking No Marking
PCB Hole Count 10
Contact Function ON-(ON)
Compliance
RoHS Status ROHS3 Compliant
