GRS-2012-2501
RoHS
RoHS compliant
RoHS compliantPackage 125
Category Switches / Rocker Switches
Description
Concave (Curved) 2000 White Panel Mount Snap-In Rocker Switch 0.288inch 12A 250V 0.75HP@250VAC
PDF
/
Buying Options
Total Price: USD $1.82
Unit Price: USD $1.824931
≥1 USD $1.824931
≥200 USD $0.72866
≥500 USD $0.703714
≥1000 USD $0.691898
Inventory: 5313
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Panel, Snap in
Mounting Type Panel Mount, Snap-In
Package / Case 125
Housing Material NYLON
Actuator Material NYLON
Center Contact Plating SILVER
End Contact Plating SILVER
Technical
Operating Temperature -20°C~105°C
Packaging Bulk
Series 2000
Feature Polarized
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Quick Connect
Current Rating (Amps) 16A AC
Current Rating 16A
Termination Style Quick Connect - 0.250 (6.3mm)
Voltage - Rated AC 125V
Body Length or Diameter 28.448mm
Body Breadth 13.716 mm
Actuator Type Concave (Curved)
Circuit SPDT
Switch Function On-On
Panel Cutout Dimensions Rectangular - 28.58mm x 13.97mm
Contact Resistance 0.01mOhm
Insulation Resistance 1000000000Ohm
Color - Actuator/Cap White
Dielectric Withstanding Voltage 2500VAC V
Electrical Life 25,000 Cycles
Mechanical Life 25,000 Cycles
Switch Type ROCKER SWITCH
Contact Current(AC)-Max 12A
Contact (AC) Max Rating R Load 12A@250VAC
Contact Voltage(AC)-Max 250V
Actuator Marking No Marking
Contact (AC) Max Power Rating R Load 0.75HP@250VAC
Dimensions
Actuator Length 0.288 inch
Compliance
RoHS Status ROHS3 Compliant
