GRS-2011-3003
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
Rocker Switches SPST 16A 125-250VAC
PDF
/
Buying Options
Total Price: USD $1.5
Unit Price: USD $1.500645
≥1 USD $1.500645
≥200 USD $0.598682
≥500 USD $0.578989
≥1000 USD $0.569799
Inventory: 6977
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mounting Type Panel Mount, Snap-In
Surface Mount NO
Housing Material NYLON
Actuator Material NYLON
Center Contact Plating SILVER
End Contact Plating SILVER
Technical
Operating Temperature -20°C~105°C
Packaging Bulk
Series 2000
Feature Polarized
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Current Rating (Amps) 16A AC
Termination Style Quick Connect - 0.250 (6.3mm)
Voltage - Rated AC 125V
Body Length or Diameter 27.1018mm
Body Breadth 6.35 mm
Actuator Type Concave (Curved)
Circuit SPST
Switch Function On-Off
Panel Cutout Dimensions Rectangular - 27.23mm x 12.19mm
Contact Resistance 0.01mOhm
Insulation Resistance 1000000000Ohm
Color - Actuator/Cap Black
Dielectric Withstanding Voltage 2500VAC V
Electrical Life 25,000 Cycles
Mechanical Life 25,000 Cycles
Switch Type ROCKER SWITCH
Contact Current(AC)-Max 12A
Contact (AC) Max Rating R Load 12A@250VAC
Contact Voltage(AC)-Max 250V
Actuator Marking No Marking
Contact (AC) Max Power Rating R Load 0.75HP@250VAC
Dimensions
Body Height 14.5288mm
Actuator Length 0.288 inch
Compliance
RoHS Status ROHS3 Compliant
