U215J21ZQE12
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
Paddle 7000 White Panel Mount Snap-In Rocker Switch 15.39mm 5A 250V -30C~85C
PDF
/
Inventory: 6000
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 24mm
Technical
Actuator Marking No Marking
Max Voltage Rating (DC) 28V
Throw Configuration DPDT, SP3T
Electrical Life 40,000 Cycles
Max Current Rating 5A
Max Voltage Rating (AC) 250V
Color - Actuator/Cap White
Panel Cutout Dimensions Rectangular - 19.05mm x 10.41mm
Switch Function Mom-On-Mom
Circuit SP3T
Actuator Type Paddle
Voltage - Rated AC 120V
Termination Style Solder Lug
Current Rating 5A
Depth 15.39mm
Current Rating (Amps) 5A AC/DC
Voltage - Rated DC 28V
Min Operating Temperature -30°C
Max Operating Temperature 85°C
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Jumper needed to achieve triple throw
Series 7000
Packaging Bulk
Operating Temperature -30°C~85°C
Physical
Actuator Material Nylon
Housing Material Stainless Steel
Mounting Type Panel Mount, Snap-In
Mount Panel, Snap in
Contact Plating Silver
Contact Material Silver
Supply Chain
Factory Lead Time 14 Weeks
