ET01J6AGE2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
Switch Rocker ON None ON SPDT PC Pins Curved Rocker 3A 120VAC 28VDC 0.4VA
PDF
/
Inventory: 8085
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Max Voltage Rating (DC) 28V
Illumination Type Illuminated
Actuator Marking No Marking
Electrical Life 60,000 Cycles
Max Current Rating 3A
Max Voltage Rating (AC) 120V
Color - Actuator/Cap Black
Switch Function On-On
Circuit SPDT
Actuator Type Concave (Curved)
Voltage - Rated AC 120V
Termination Style PC Pin
Current Rating 3A
Orientation Right Angle
Current Rating (Amps) 3A AC/DC
Voltage - Rated DC 28V
Power Rating 400mW
Termination PC Pins
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Sealed - Flux Protection
Series ET
Published 2012
Packaging Tray
Operating Temperature -30°C~85°C
Dimensions
Length 14.73mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Physical
Actuator Material Nylon
Mounting Type Through Hole, Right Angle
Mount Brackets, Through Hole
Contact Plating Gold
Contact Material Silver
Supply Chain
Factory Lead Time 10 Weeks
