C222J12S205DQA
RoHS
/
Package /
Category Switches / Rocker Switches
Description
Switch Rocker ON OFF DPST Quick Connect Rocker 15A 250VAC
PDF
/
Inventory: 3274
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Copper
Contact Plating Silver
Mount Panel, Snap in
Mounting Type Panel Mount, Snap-In
Housing Material Nylon
Actuator Material Nylon
Technical
Operating Temperature -30°C~65°C
Packaging Bulk
Published 2003
Series C
Feature Positive Detent
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Quick Connect
Max Operating Temperature 65°C
Min Operating Temperature -30°C
Current Rating (Amps) 15A AC
Orientation Straight
Current Rating 15A
Termination Style Quick Connect - 0.250 (6.3mm)
Voltage - Rated AC 125V
Actuator Type Concave (Standard V)
Housing Color Black
Circuit DPST
Switch Function On-Off
Panel Cutout Dimensions Rectangular - 28.50mm x 25.40mm
Color - Actuator/Cap Black
Max Voltage Rating (AC) 250V
Max Current Rating 15A
Electrical Life 10,000 Cycles
Throw Configuration DPST
Actuator Marking ON OFF, Vertical
Dimensions
Length 31.75mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
