7301J10ZBE2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
SWITCH ROCKER 3PDT 0.4VA 20V
PDF
/
Inventory: 9172
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Contact Plating Gold
Mount Flanges, Panel
Mounting Type Panel Mount, Flange
Housing Material Stainless Steel
Actuator Material Nylon
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Published 2016
Series 7000
Feature Epoxy Sealed Terminals
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Power Rating 400mW
Voltage - Rated DC 20V
Current Rating (Amps) 0.4VA AC/DC
Depth 16.51mm
Termination Style Solder Lug
Voltage - Rated AC 20V
Actuator Type Concave (Curved)
Circuit 3PDT
Switch Function On-On
Panel Cutout Dimensions Rectangular - 34.92mm x 16.46mm
Color - Actuator/Cap Black
Max Voltage Rating (AC) 20V
Electrical Life 100,000 Cycles
Throw Configuration 3PDT
Max Voltage Rating (DC) 20V
Actuator Marking No Marking
Dimensions
Length 47.63mm
Compliance
RoHS Status ROHS3 Compliant
