7213J16W3QE32
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
SWITCH ROCKER SP3T 5A 120V
PDF
/
Buying Options
Total Price: USD $29.17
Unit Price: USD $29.172638
≥1 USD $29.172638
Inventory: 2572
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 25.04mm
Technical
Actuator Marking No Marking
Max Voltage Rating (DC) 28V
Throw Configuration DPDT, SP3T
Electrical Life 40,000 Cycles
Max Current Rating 5A
Max Voltage Rating (AC) 250V
Color - Actuator/Cap Red
Panel Cutout Dimensions Rectangular - 20.32mm x 12.70mm
Switch Function On-On-Mom
Circuit SP3T
Actuator Type Concave (Standard V)
Voltage - Rated AC 120V
Termination Style Wire Wrap
Current Rating 5A
Depth 15.62mm
Current Rating (Amps) 5A AC/DC
Voltage - Rated DC 28V
Min Operating Temperature -30°C
Max Operating Temperature 85°C
Termination Wire Wrap
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Jumper needed to achieve triple throw
Series 7000
Packaging Bulk
Operating Temperature -30°C~85°C
Physical
Actuator Material Nylon
Housing Material Stainless Steel
Mounting Type Panel Mount, Snap-In
Mount Panel, Snap in
Contact Plating Silver
Contact Material Silver
Supply Chain
Factory Lead Time 14 Weeks
