7208J1ABE2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
Concave (Standard V) 7000 Black Through Hole Right Angle Rocker Switch 29.03mm 0.4VA AC/DC 20V -30C~85C
PDF
/
Buying Options
Total Price: USD $23.43
Unit Price: USD $23.433952
≥1 USD $23.433952
Inventory: 7421
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Contact Plating Gold
Mount Brackets, Through Hole
Mounting Type Through Hole, Right Angle
Housing Material Stainless Steel
Actuator Material Nylon
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Published 2016
Series 7000
Feature Epoxy Sealed Terminals
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Power Rating 400mW
Voltage - Rated DC 20V
Current Rating (Amps) 0.4VA AC/DC
Depth 29.03mm
Termination Style PC Pin
Voltage - Rated AC 20V
Actuator Type Concave (Standard V)
Circuit DPDT
Switch Function On-Mom
Color - Actuator/Cap Black
Max Voltage Rating (AC) 20V
Electrical Life 40,000 Cycles
Throw Configuration DPDT
Max Voltage Rating (DC) 20V
Actuator Marking No Marking
Dimensions
Length 16.87mm
Compliance
RoHS Status ROHS3 Compliant
