7207J3ZQE2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
SWITCH ROCKER DPDT 5A 120V
PDF
/
Buying Options
Total Price: USD $13.73
Unit Price: USD $13.725329
≥1 USD $13.725329
≥10 USD $12.948428
≥100 USD $12.215497
≥500 USD $11.524061
≥1000 USD $10.871748
Inventory: 1155
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 41.28mm
Technical
Actuator Marking No Marking
Max Voltage Rating (DC) 28V
Throw Configuration DPDT
Electrical Life 40,000 Cycles
Max Current Rating 5A
Max Voltage Rating (AC) 250V
Color - Actuator/Cap Black
Panel Cutout Dimensions Rectangular - 27.81mm x 16.46mm
Switch Function On-Off-Mom
Circuit DPDT
Actuator Type Concave (Standard V)
Voltage - Rated AC 120V
Termination Style Solder Lug
Current Rating 5A
Depth 15.11mm
Orientation Straight
Current Rating (Amps) 5A AC/DC
Voltage - Rated DC 28V
Min Operating Temperature -30°C
Max Operating Temperature 85°C
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Epoxy Sealed Terminals
Series 7000
Published 2010
Packaging Bulk
Operating Temperature -30°C~85°C
Physical
Actuator Material Nylon
Housing Material Stainless Steel
Mounting Type Panel Mount, Flange
Mount Flanges, Panel
Contact Plating Silver
Contact Material Silver
Supply Chain
Factory Lead Time 14 Weeks
