7205J91CQE22
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
SWITCH ROCKER DPDT 5A 120V
PDF
/
Buying Options
Total Price: USD $15
Unit Price: USD $15.000113
≥1 USD $15.000113
≥10 USD $14.151054
≥100 USD $13.350042
≥500 USD $12.594386
≥1000 USD $11.881495
Inventory: 7811
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Contact Material Silver
Contact Plating Silver
Mount Panel, Snap in, Through Hole
Mounting Type Panel Mount, Snap-In
Housing Material Stainless Steel
Actuator Material Nylon
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Published 2010
Series 7000
Feature Epoxy Sealed Terminals
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pins
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Voltage - Rated DC 28V
Current Rating (Amps) 5A AC/DC
Depth 15.62mm
Current Rating 5A
Termination Style PC Pin
Voltage - Rated AC 120V
Actuator Type Paddle
Circuit DPDT
Switch Function Mom-Off-Mom
Panel Cutout Dimensions Rectangular - 15.24mm x 12.70mm
Color - Actuator/Cap Black
Max Voltage Rating (AC) 250V
Max Current Rating 5A
Electrical Life 40,000 Cycles
Throw Configuration DPDT
Max Voltage Rating (DC) 28V
Actuator Marking No Marking
Dimensions
Length 19.43mm
Compliance
RoHS Status ROHS3 Compliant
