7201J90V2BE2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
Paddle 7000 Black Through Hole Rocker Switch 11.43mm 0.4VA AC/DC 20V -30C~85C
PDF
/
Inventory: 9406
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 19.56mm
Technical
Actuator Marking No Marking
Max Voltage Rating (DC) 20V
Throw Configuration DPDT
Electrical Life 100,000 Cycles
Max Voltage Rating (AC) 20V
Color - Actuator/Cap Black
Switch Function On-On
Circuit DPDT
Actuator Type Paddle
Voltage - Rated AC 20V
Termination Style PC Pin
Depth 11.43mm
Current Rating (Amps) 0.4VA AC/DC
Voltage - Rated DC 20V
Power Rating 400mW
Min Operating Temperature -30°C
Max Operating Temperature 85°C
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Epoxy Sealed Terminals
Series 7000
Published 2008
Packaging Bulk
Operating Temperature -30°C~85°C
Physical
Actuator Material Nylon
Housing Material Stainless Steel
Mounting Type Through Hole
Mount Brackets, Through Hole
Contact Plating Gold
Supply Chain
Factory Lead Time 14 Weeks
