7201J60V3QE2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
Paddle 7000 Black Through Hole Rocker Switch 11.43mm 5A 250V -30C~85C
PDF
/
Buying Options
Total Price: USD $29.24
Unit Price: USD $29.240909
≥1 USD $29.240909
Inventory: 3066
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Contact Material Silver
Contact Plating Silver
Mount Brackets, Through Hole
Mounting Type Through Hole
Housing Material Stainless Steel
Actuator Material Nylon
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Published 2008
Series 7000
Feature Epoxy Sealed Terminals
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Voltage - Rated DC 28V
Current Rating (Amps) 5A AC/DC
Depth 11.43mm
Current Rating 5A
Termination Style PC Pin
Voltage - Rated AC 120V
Actuator Type Paddle
Circuit DPDT
Switch Function On-On
Color - Actuator/Cap Black
Max Voltage Rating (AC) 250V
Max Current Rating 5A
Electrical Life 100,000 Cycles
Throw Configuration DPDT
Max Voltage Rating (DC) 28V
Actuator Marking No Marking
Dimensions
Length 16.26mm
Compliance
RoHS Status ROHS3 Compliant
