7201J2V5QE2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
SWITCH ROCKER DPDT 5A 120V
PDF
/
Inventory: 4310
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Contact Material Silver
Contact Plating Silver
Mount Brackets, Through Hole, Vertical
Mounting Type Through Hole, Right Angle, Vertical
Housing Material Stainless Steel
Actuator Material Nylon
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Published 2008
Series 7000
Feature Epoxy Sealed Terminals
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Voltage - Rated DC 28V
Current Rating (Amps) 5A AC/DC
Depth 44.63mm
Current Rating 5A
Termination Style PC Pin
Voltage - Rated AC 120V
Actuator Type Paddle
Circuit DPDT
Switch Function On-On
Color - Actuator/Cap Black
Max Voltage Rating (AC) 250V
Max Current Rating 5A
Electrical Life 100,000 Cycles
Throw Configuration DPDT
Max Voltage Rating (DC) 28V
Actuator Marking No Marking
Dimensions
Length 11.43mm
Compliance
RoHS Status ROHS3 Compliant
